CE100 Control unit estendible from 2 up to 6 sensors
This control panel represents the first step toward the professional industrial gas detection. To be installed exclusively on DIN rail for connections up to a maximum of 6 sensors, it is conceived to be used also in “DIN” ra… See more...
This control panel represents the first step toward the professional industrial gas detection.
To be installed exclusively on DIN rail for connections up to a maximum of 6 sensors, it is conceived to be used also in “DIN” rail with other modules, on the same DIN rail for various configurations according to the installation requirements.
- Compact system
- Backlighted display
- Reading in real time of all sensors connected
- Compatible with all sensors series “SE” and “TS”
- Sensors pre-programming
- 24 different configuration system
- Flexible programming and extremely complete
- 3 alarm relay (for all sensors)
- 1 fault relay (fault)
- Lithium battery in DIN rail
- Protected by a password
- GS102 GSM controller – In accordance with :
Directive195/5/CE
EN 301 489-7 V1.1.1 (2000-09)
EN 301 511 V7.01.1 (2000-12)
EN 60950 (2000)
Standard Specifications
Power supply: 12÷24Vdc
Installation: DIN rail
Absorption: 4VA without connected sensors- 8VA with 2 connected sensors - 12VA with 4 connected sensors- 15VA with 8 connected sensors
Alarm level: Programmable
Measuring range: Programmable
